Full Truck Test Lane (18 ton) – STT45 with Load Simulation Lift Kit

Blackfern Member Terms
3, 6 or 12 months deferred payments

The STT45 Truck Test Lane includes a Brake tester with lift bed, a Slide slip tester, and an 8-way freeplay detector.

The STT45 split bed brake tester is our heaviest tester capable of 18 Ton axle load.

The STT45 is available as a full kit or as standalone item/s and is NZTA COF approved.

"The works! Durable and super heavy duty"

• 18,000kg Axle Load
• 40kn per wheel brake force
• 0-40kn measure range
• 600-1100mm wheel diameter
• 4 post per axle hydraulic lift kit
• 4wd brake testing capability *optional
• 1000-3000mm, 1100-3100mm and 1200-3200mm track width options
• 248 x 1000mm rollers
• >0.7 / 0.6 coef. friction (dry/wet)
• Locking rollers for easy exit
• NZTA COF approved
• Selectable Car Mode
• Reliable software and imagery with accurate and repeatable test results

BROCHURE
